Tafel
|
|
Benennung
|
Anzahl
|
Bestell-Nr.
|
4
|
1
|
Kupplungsschwungrad
|
1
|
2614 K 3
|
4
|
1a
|
Druckfeder
|
8
|
2654 K 41
|
4
|
1b
|
Tellerfeder
|
1
|
7444 K 1
|
4
|
1c
|
Paßfeder 5 x 5 x 12
|
1
|
DIN 6885
|
4
|
1d
|
Sicherungsscheibe
|
1
|
7164 K 10
|
4
|
1e
|
Sechskantschraube
|
1
|
7334 K 14
|
4
|
2
|
Drucklamelle mit Teil, Bild 2a
|
1
|
2690 K 16
|
4
|
2
|
bis Motor Nr. 35/2285
|
1
|
|
4
|
2
|
ab Motor Nr. 35/2286 siehe Montage-Hinweis
|
1
|
|
4
|
2a
|
Druckpilz
|
1
|
7244 K 3
|
4
|
2b
|
Kupplungslamelle (im Austausch)
|
1
|
2690 K 14
|
4
|
2c
|
Decklamelle
|
1
|
2694 K 7
|
4
|
2c
|
Decklamelle, verstärkte Ausführung
|
1
|
2694 K 7
|
4
|
2d
|
Sprengring
|
1
|
7154 K 3
|
4
|
3
|
Kupplungsdrucklager
|
1
|
2740 K 2
|
4
|
3
|
ab Motor Nr. 35/664 bis Motor Nr. 35/2285
|
1
|
2741 K 2
|
4
|
3
|
ab Motor Nr. 35/2286 siehe Montage Hinweis
|
1
|
2742 K 2
|
4
|
3a
|
Filzring
|
1
|
7025 K 39
|
4
|
3b
|
Kupplungsdruckbolzen
|
1
|
7034 K 32
|
4
|
3b
|
bis Motor Nr. 35/663
|
1
|
|
4
|
3b
|
ab Motor Nr. 35/664
|
1
|
7034 K 37
|
4
|
3b
|
ab Motor Nr. 35/2356 siehe Montage-Hinweis
|
1
|
|
4
|
3c
|
Kugel 6 mm
|
1
|
38-03-032
|
4
|
3d
|
Kupplungsdruckbolzen
|
1
|
7034 K 36
|
4
|
3d
|
ab Motor Nr. 35 2286 siehe Montage-Hinweis
|
1
|
|
4
|
3e
|
Dichtungskappe
|
1
|
7324 K 1
|
4
|
3f
|
Dichtring
|
1
|
7025 K 13
|
4
|
4
|
Kupplungshebel
|
1
|
2664 K 1
|
4
|
4a
|
Druckfeder
|
1
|
2654 K 32
|
4
|
4b
|
Bolzen mit Kopf 8h 11 x 40 x 35
|
1
|
DIN 1434
|
4
|
4c
|
Scheibe
|
1
|
8 DIN 1440
|
4
|
4d
|
Splint 2 x 12
|
1
|
DIN 94
|
4
|
4e
|
Kugel 6 mm
|
1
|
38-03-032
|
4
|
4f
|
Kupplungsstell-Schraube
|
1
|
7180 K 1
|
4
|
4g
|
Sechskantmutter M 10 x 1
|
1
|
DIN 936
|
